302 304 316 316L 5 10 25 50 100 200 micron stainless steel wire mesh

FOB Reference Price:Get Latest Price
$0.65 - $6.50 / Square Meters | 2 Square Meter/Square Meters (Min. Order)
Wire Diameter:
customer size 0.0203--4.0mm 0.0008-0.157Inches
customer size 0.0203-21.4mm 0.008-0.84Inches
Lead Time:
Quantity(Square Meters) 1 - 150 >150
Est. Time(days) 7 Negotiable
Report Suspicious Activity
Quick Details
Place of Origin:
Hebei, China (Mainland)
Stainless Steel Wire
Wire Cloth
Weave Style:
Dutch/Plain/Twill Weave, Dutch Weave/Plain Weave/Twill Weave/reverse dutch Weave
Model Number:
Brand Name:
key word:
stainless steel metal mesh
particle separation, filtering, safety and security
Production Experience:
15 years
main exported districts:
USA, EU and Japan, etc
meet clients' internal specifications, ISO, ASTM and DIN
minimum standard.:
ASTM E2016
the max mesh of plain weave:
Supply Ability
Supply Ability:
500000 Square Meter/Square Meters per Year
Packaging & Delivery
Packaging Details
inner kraft, outside plastic cloth, put into wooden pallet or case
Lead Time :
Quantity(Square Meters) 1 - 150 >150
Est. Time(days) 7 To be negotiated
302 304 316 316L 5 10 25 50 100 200 micron stainless steel wire mesh

Usage: Filters, sieve, chemical industry, mine industry, paper-making , etc

Material: SS 201,202,304,304L, 316,316L, 321, 430, etc

Woven style: Plain, Twill, Dutch Twill, Reverse Dutch, Five-Heddle

Mesh : 1-635mesh

Diameter: 0.0008"-0.08"

Packaging Details: Inner kraft, outside plastic cloth,put into wooden pallet or case

Delivery Time: 5 days for stock material

Have exported: USA, EU, Japan and etc




Wire diameter


OPen Area

Weight (LB) /100 Square Foot

Plain,Twill Weave Wire Mesh

1 × 1-635 × 635


25 to 84.6

2.53 to 41.1



Wire diameter


Absolute Filtration Finess µm

Nominal Filtration Finess µm

Plain Dutch Weave Wire Mesh

8 × 85-80 × 400

0.014'' × 0.0126''- 0.0049'' × 0.0028''

318-340 to 43-48

250-255 to 35-40

Twill Duntch Weave Wire Mesh

20 × 250 - 500 × 3200

0.0098'' × 0.0079'' - 0.0015'' × 0.0010''

110-120 to 8-9

98-105 to 2-3

1.How to make a inquiry of stainless steel wire mesh ?

You need to provide material,mesh number, wire diameter,size and the quantity to ask an offer, you can also indicate if you have any special requirement. We'll providea formal quotatiom list after your inquiry received.


2.Could you provide free sample ?

Yes, we can provide free sample in half A4 size together with our catalogue. But the courier charge will on your side. We'll send back the courier charge if you make an order.


3.How is your Payment Term ?

Generally, our payment term is T/T 30% in advance and the balance 70% against the copy of B/L. Other payment term we can also discuss.


4.How is your delivery time ?

We always prepare enough stock material for your urgent requirement, the delivery time is 7 days for all the stock material. We'll check with our production department for the non-stock items to offer you the exact delivery time and producing schedule.
